1、Non induction winding structure of metallic polypropylene membrane.
2、lt is small in bulk, has long life-span and good self-healing characteristic.
High insulating resistance, little temperature changing inside,excellentstability of capacitance.
3、Non-toxic and non-leaking, profit environmental protection.
1、Use round plastic shell, and insulation sealed lid for sealing, plastic lid forsealing or resin for sealing.
2、Flat bottom or fixing stud M8*12
3、Fasten terminals, Lug, wire,cable.
4、Plastic can, ABS ,PC.
1、Suitable for starting and operating 50Hz(60Hz)AC single-phaseelectromotor.
2、Widely used as the start-up and running capacitor that is special for microwater pump, cleaning machine,washing machine, and single -phasehousehold electrical appliances.
